This lecture assumes you can open a terminal, type a command, and press Enter. It does not assume you already know what a process, a file descriptor, or the kernel is. New words get a definition in the same paragraph.

Words we will use

One-sentence crystal

The “terminal” is several programs plus a slice of the kernel: the window draws pixels and owns one end of a fake serial cable (a PTY); the kernel may edit or echo your typing; the shell is a child reading the other end; variables and external commands live in copies of memory, not in one box.

---

Level 1 — Why “just type” is not enough

A beginner points at the rectangle and says: “That is one program.” Then ordinary failures have no names.

You do not need ioctl trivia to use a computer. You need to name the actor when the happy path ends: window, PTY, kernel manners, shell, child, environment copy. Day to day, still just type. The map is for the first unexplained failure—so you do not reboot because echo died (stty had four flags wrong).

The window is a frame. The shell and your commands are the specimen. The frame matters; it is not the cell.

---

Level 2 — The big picture (architecture)

2.1 Three things people mash into one word

Say these out loud until they feel different:

1. Terminal emulator = the window app. It talks to the graphical system (Wayland or X11 on Linux), draws glyphs, and holds the master end of a fake cable.
2. PTY (pseudo-terminal) = a pair of devices inside the kernel that pretend to be an old serial terminal (a teletype, historically TTY). One end is master, one end is slave. Bytes written on one end can be read on the other.
3. Shell = the interpreter process (bash / zsh / …) attached to the slave. It is a customer of the PTY, not the PTY itself.

/dev/tty means: “whatever terminal this process is attached to.” It is an alias, like “my house” rather than a street number.

The Linux console (Ctrl+Alt+F3, device /dev/tty3, …) is a different path: real text console, often no GUI emulator. Same kind of line discipline; different glass.

2.2 Six layers, from your finger to the kernel

Six layers ≠ six processes. Some are parts of one program. Some are kernel code you never “start.”

Numbered in the order a keystroke travels:

  You type
    → 1 Glass     window
    → 2 Paint     emulator logic
    → 3 Master    PTY master (still the window process)
         ║  kernel
    → 4 Manners   n_tty + slave
         ║  userspace
    → 5 Shell     read(0)
    → 6 Core      if the command needs a syscall (almost always)

The shell is not “below” the kernel in importance. It is a userspace process whose stdin/stdout are the slave. Manners (4) sit on the wire.

2.3 The window is a tree of processes

Claim: one open terminal window is at least two processes, often three.

 Process A   Terminal emulator     “the window.” Lives until you close it.
      │
      │  The emulator asks the kernel: copy me, then become a shell.
      │  (The usual pair of requests is called fork, then execve.
      │   We will say what those words mean in Level 3.)
      ▼
 Process B   Interactive shell     Prints the prompt. Lives until the session ends.
      │
      │  Only if you run an *external* program (a file such as /usr/bin/ls)
      ▼
 Process C   That program          Lives only until that program exits.

Builtin versus external (say this until it is boring)

• A builtin is a command the shell implements itself. Examples in bash/zsh: cd, export, jobs, and usually pwd. No Process C. The work happens inside Process B.
• An external command is a file the kernel can run, found via PATH (a list of directories). Examples: /usr/bin/ls, /usr/bin/grep, /usr/bin/python3. The shell creates a child and replaces that child’s program image with the file, then waits.

type pwd tells you which story your shell uses.

2.4 Variables: two boxes, only one is inherited

A variable is a named string in memory (NAME=value). It is not “a setting of the window.” It belongs to a process.

There are two boxes inside the shell:

The one-way rule (memorize this):

1. Parent → child: the child receives a copy of the exported list when it starts (execve).
2. Child → parent: if the child changes a variable, the parent does not change. There is no “write back.”

That is why “it works when I type it” and “it fails in a script / cron / systemd” so often: those other worlds never saw your unexported GUI-shell variables.

---

Level 3 — The story of one command

3.1 You type pwd and press Enter

We assume:

• a normal prompt (the line discipline is in canonical / “cooked” mode: wait for Enter);
• pwd is a builtin;
• therefore only two processes exist: emulator + shell.

Phase A — Down: key → bytes → shell wakes up

1. 1 Glass. You press keys. The window system turns that into events (“key p down”) and gives them to the emulator process.
2. 2 Paint. The emulator maps them to p, w, d, then Enter. Enter is often CR (0x0D). Payload: 0x70 0x77 0x64 0x0D.
3. 3 Master. The emulator writes those bytes into its PTY master fd.
4. 4 Manners (n_tty). Echo: copies go back to the master so you see letters before the shell has the whole line. Buffer: the line sits in kernel memory; the shell is still in read(). Enter: CR usually becomes NL (0x0A); the kernel wakes the shell.
5. 5 Shell. read(0, …) returns pwd\n. stdin is the slave. The shell parses a builtin and does not create Process C.
6. 6 Core. The builtin asks getcwd (or uses its own PWD—shells differ). The kernel returns a path such as /home/you.

Phase B — Up: path string → pixels

7. 5 Shell. Writes /home/you\n to stdout (fd 1), then a new prompt. fd 1 is the same slave.
8. 4 Manners. May turn NL into CR+NL (old printers). Bytes move toward the master.
9. 3 Master. The emulator reads the master.
10. 2 Paint. Updates the grid of cells.
11. 1 Glass. Fonts become pixels. You see the path.

If you run /usr/bin/pwd instead

After step 5 the shell says: this is a file, not a builtin.

1. fork — kernel clones the shell into a child (Process C). Clone means: same open files, same variables for a moment.
2. execve("/usr/bin/pwd", …) — the child throws away the shell program and becomes pwd. The environment copy is installed here.
3. waitpid — the original shell sleeps until Process C exits, then prints the next prompt.

While /usr/bin/pwd runs, ps can show three PIDs. When it exits, you are back to two.

3.2 Connecting commands (|, ;, &&, ||)

Exit code: every process ends with a small integer. 0 means success by convention. The shell stores the last one in $?.

A pipe is not “do A, then do B.” It is:

1. Shell asks the kernel for a pipe: a small in-memory buffer with a write end and a read end.
2. Shell starts two children.
3. Left command’s stdout is attached to the write end.
4. Right command’s stdin is attached to the read end.
5. Both run together. If the left produces faster than the right consumes, the buffer fills and the kernel pauses the left. If the right is hungry, it waits. That pause is called back-pressure. You do not implement it; the kernel does.

3.3 Signals, then the steering wheel (foreground and background)

A signal is a kernel-to-process telegram. It has a name (SIGINT) and a default disposition (what happens if the program did not install a handler): die, stop, continue, or ignore. The shell and the line discipline are simply two common senders. You can also send by hand: kill -INT <pid> is the same family of event as Ctrl+C, aimed at a PID you chose.

A table of signals you will actually meet

Numbers can differ on other Unixes. Trust kill -l on your host.

Two facts beginners mix:

1. Ctrl+Z is not kill. It pauses. jobs still lists the job. fg or bg sends SIGCONT.
2. & is not “run on another computer.” It is “start this job without giving it the steering wheel.” The CPU still runs it. The TTY does not belong to it.

Foreground vs background

Imagine one steering wheel per session (one controlling TTY).

A pipeline cat | grep foo is one job (one process group). One Ctrl+C is meant to SIGINT both ends.

Closing the window is not Ctrl+C. The emulator drops the PTY master. The kernel sends SIGHUP to the session. Foreground and background jobs both die unless they have been detached from that fate: nohup, disown, or a multiplexer such as tmux (a different engine, with its own PTYs).

Ctrl+C in one sentence: if isig is on, byte 0x03 is not given to the program as a character; the kernel sends SIGINT to the foreground process group.

Shell verbs (Level 4 preview)

long-job &          # start in background; prints a job number, e.g. [1] 4521
jobs                # list jobs of *this* shell
fg                  # last job → foreground
fg %1               # job number 1 → foreground
bg %1               # continue job 1 in background (after Ctrl+Z)
kill %1             # SIGTERM the job (the group), not a random PID
disown %1           # this shell will not SIGHUP it on exit (still dies if the TTY vanishes, unless nohup/tmux)
nohup long-job &    # ignore SIGHUP; log to nohup.out by default

%1 is a job spec. It is not a PID. ps shows PIDs; jobs shows the shell’s own numbering.

Real situations (how to apply the skill)

Scenario A — Compile or test while you keep the prompt

• Problem: npm test or make -j takes minutes. You still need to git status.
• Correct: make -j8 & then work. jobs to see it. If the compiler prints too much, redirect: make -j8 >build.log 2>&1 &.
• Wrong: opening five extra GUI windows because you think the prompt is “busy.” The prompt is busy only if the job is foreground.
• Expert note: if the job must outlive this window, & is not enough. Use tmux (or a systemd unit). Background ≠ immortal.

Scenario B — You started in the foreground and need the prompt back

• Problem: you forgot &. rsync is running. You need to check disk.
• Correct: Ctrl+Z (SIGTSTP) → bg (SIGCONT without the wheel) → df -h. fg if you must watch rsync again.
• Wrong: Ctrl+C “to get the prompt” and then restart a two-hour copy.
• Expert note: Ctrl+Z is a surgical pause. Experts reach for it the way they reach for a turn signal—not as a crash.

Scenario C — A tool that wants the keyboard (vim, top, a password prompt, ssh)

• Problem: you ran vim file & or docker attach … &.
• What happens: the editor is background. The first time it reads the TTY, SIGTTIN stops it. The screen looks “frozen” or garbled.
• Correct: interactive programs stay foreground. fg if you already blundered.
• Expert note: experts never background a program whose job is to be the viewfinder. They background producers (builds, downloads, servers that log to a file), not consumers of stdin.

Scenario D — Long remote job over a flaky network

• Problem: ssh host then ./migrate.py in the foreground. VPN drops → SIGHUP → migration dies.
• Correct: on the server, tmux new -s migrate then run the job (see the tmux how-to). Detach. Close the laptop.
• Almost correct: nohup ./migrate.py >migrate.log 2>&1 & — survives hangup, but you have no live TTY to watch; you tail -f the log. Fine for fire-and-forget.
• Wrong: ./migrate.py & inside the SSH shell, then close the laptop. Background still receives SIGHUP with the session.

Scenario E — A pipeline you must stop cleanly

• Problem: journalctl -f | grep --line-buffered error.
• Correct: leave it foreground. Ctrl+C hits the whole group.
• Wrong: background it, then kill only grep. journalctl may become an orphan still writing. Prefer kill %n (the job) or foreground + Ctrl+C.

Scenario F — A service that should not live in your TTY at all

• Problem: python app.py & on a server “so it keeps running.”
• Correct for a toy: tmux or nohup plus a log.
• Correct for production: a systemd unit (restart policy, journal, user). The TTY is a classroom, not an init system.
• Expert note: experts ask “must a human be attached?” If no, the answer is rarely &.

How experts think about foreground and background

The expert decision procedure (use this until it is muscle):

1. Does this program need stdin or a live full screen? → Foreground.
2. Do I only need CPU + a log, and I want this prompt? → Background, redirect fds, jobs to watch.
3. Must it survive this window / this SSH? → tmux (human will return) or systemd (the machine should own it). & is not step 3.
4. Must I stop it? → Prefer the job (Ctrl+C in fg, or kill %n) over kill -9 of a guessed PID.

Three questions: who holds the wheel, who must outlive the wheel, which telegram you are sending.

3.4 Cooked mode vs raw mode

A “broken terminal” after you kill a full-screen program is usually leftover raw + no echo: you type and see nothing; Enter does not behave. The computer is not cursed. You restore cooked manners with reset or stty sane (Level 5).

---

Level 4 — What you actually type

4.1 Variables

# Local to this shell only. No spaces around =  (spaces break the command).
LOCAL_VAR="linux"

# Put it in the inherited list (promote), or create already exported:
export LOCAL_VAR
export GLOBAL_VAR="production"

# Give ONE command a variable without changing the parent shell:
LOG_LEVEL=debug python3 app.py

# Take it out of the inherited list, then delete it entirely
# (declare +x is bash; in zsh use typeset +x):
declare +x GLOBAL_VAR
unset GLOBAL_VAR

Names you will see constantly:

Making them survive a new window is just “run these assignments when a shell starts”:

A systemd service has its own Environment= lines. It will not automatically see variables you exported only in a GUI terminal.

4.2 Asking the line discipline what it is doing

stty -a

You do not need to memorize the C structure. Remember three switches:

4.3 Colours and cursor moves are still bytes

When vim “clears the screen,” it writes ESC sequences (\033…) into the same stdout pipe. Layer 2 (Paint) interprets them. $TERM names a terminfo dictionary. A wrong $TERM over SSH means the host lacks that dictionary, not that “Linux is broken.”

Resizing the window is a separate message (SIGWINCH / window-size ioctl), not something you must type as ESC yourself.

---

Level 5 — Do this on your machine

Use a throwaway terminal window. After each command, read the output and match it to a sentence above.

# 1) Who am I, and which fake cable is this?
tty                    # expect something like /dev/pts/3
echo "This shell's PID is $$"

# 2) Family tree of this session (PID, parent PID, terminal, command)
ps -o pid,ppid,tty,cmd

# 3) Line-discipline switches (look for icanon echo isig)
stty -a | head

# 4) Is pwd a builtin or a file?
type pwd
type -a pwd            # may show both a builtin and /usr/bin/pwd

pwd                    # builtin path: usually NO extra process
/usr/bin/pwd           # file path: a third process exists briefly

Inheritance (the copy rule):

export DEMO=parent
bash -c 'echo child sees DEMO=$DEMO; DEMO=child; echo child changed it to $DEMO'
echo "parent still has DEMO=$DEMO"    # still "parent"

One-shot environment:

unset DEMO
DEMO=only python3 -c 'import os; print("python sees", os.environ.get("DEMO"))'
echo "parent DEMO is [${DEMO-}]"     # empty

Operators:

false ; echo "semicolon still runs this"
false && echo "you should NOT see this"
false || echo "or-runs because false failed"

# Two programs at once, kernel buffer between them:
printf 'hello\nworld\n' | grep world

Restore a smashed TTY (optional; type the second line even if you see no echo):

stty raw -echo
stty sane

If the second line is hard to type, run reset and press Enter.

Job control (do this in order):

sleep 300                 # foreground: no prompt
# Ctrl+Z                  # SIGTSTP — process still exists
jobs -l                   # [1]+ Stopped  sleep 300
ps -o pid,pgid,stat,cmd | grep sleep   # STAT is T (stopped)
bg                        # SIGCONT, still no wheel
jobs -l                   # Running
# try:  (sleep 300 &)     # already background
# type:  fg               # take the wheel again
# Ctrl+C                  # SIGINT — sleep dies

Background cannot steal the keyboard:

cat &                     # cat wants stdin
jobs -l                   # often Stopped (tty input) — SIGTTIN
fg                        # now cat holds the wheel; Ctrl+C to leave

Second window: ps -o pid,pgid,stat,cmd while you Ctrl+Z / bg / fg. Watch STAT (T vs S) and PGID.

Hangup vs background (optional, use a throwaway SSH): sleep 300 & then close the SSH client. The sleep is usually gone. Repeat inside tmux; detach; close the client; the sleep remains. That is the difference & does not teach.

---

Closing

We started with a naming error (one window, one process) and ended with a tree, a six-layer byte path, and an environment that only travels downward. Ctrl+C, export, |, and a “dead” terminal are stories you can finish once the nouns are long enough.

Open edge: With no window at all—serial getty, machine console—which of the six layers vanish, and which part of n_tty stays the same?
